HMC1290 Kab rov tav Machining Center

Qhov loj me: 1360 * 700
Kev ncig ntawm X / Y / Z axis 1200 * 800 * 700 mm
φ50 * 10 HIWIN / PMI ntsia hlau lead, X55, Y45 HIWIN / PMI pob kab qhia, spindle BT50-190-6000, BT50 disc hom ntawv xov xwm ntawm 24 cov cuab yeej

Xa kev nug

Tsham tam sim no

Hauj lwm lawm

Kev tsis

Khoom Taw qhia ntawm HMC1290 Kab rov tav Machining Center

Qhov loj me: 1360 * 700

Kev ncig ntawm X / Y / Z axis 1200 * 800 * 700 mm

φ50 * 10 HIWIN / PMI ntsia hlau lead, X55, Y45 HIWIN / PMI pob kab qhia, spindle BT50-190-6000, BT50 disc hom ntawv xov xwm ntawm 24 cov cuab yeej

Specification ntawm cnc machining chaw

HMC tshuab kev muag khoom

Lub npe				HMC1290 CNC tshuab technical parameter
				Spec	Chav tsev
Lub rooj ua haujlwm	Worktable loj			1360×700	mm
	Worktable max. thauj khoom			1000	kg
	T-qhov dimension			5-18-122	mm / ib
Mus ncig	X-axis taug kev			1200	mm
	Y-axis taug kev			Tsau 800 (ntxiv rau cov lus teb 620)	mm
	Z-axis taug kev			700	mm
	Kev ncua deb ntawm spindle kawg mus rau lub rooj ua haujlwm		Max.	880	mm
			Min.	180	mm
	Qhov deb ntawm spindle center rau Z-axis qhia nto			332	mm
Spindle	Spindle taper (7:24)			BT 50 φ190
	Ceev			8000	r / min
	Spindle lub cev muaj zog			15	kws
Pub	Kev nrawm nrawm	X-axis		12	m/min
		Y-axis		12
		Z-axis		12
	Feedrate			1-10000	hli/min
Phau ntawv xov xwm	Hom ntawv xov xwm			Hom Disc
	Magazine muaj peev xwm			24	ib daim
	Lub sijhawm hloov cuab yeej			2.5	s
Positioning precision	Precision detection txheem			JISB6336-4:2000/ GB/T18400.4-2010
	X/Y/Z-axis			±0.008	mm
X / Y / Z-axis rov ua qhov tseeb				±0.005	mm
Zuag qhia tag nrho				3600×3800×2800	mm
Tshuab hnyav				8000	kg
